TECHNICAL FEATURES
| Type standard design | Eanos |
|---|---|
| Tare | 24,5 t ± 2% |
| Axle Load | 22,5 t |
| Maximum Load | 65,5 t |
| Track Gauge | 1.435 mm |
| Length buffer to buffer | 15.740 mm |
| Distance between bogie pivots | 10.700 mm |
| Loading length | 14.484 mm |
| Loading Width | 2.712 mm |
| Loading volume | 82,5 m³ |
| Loading Surface | 39,3 m² |
| Loading Height | 1.232 mm |
| Wall height | 2.100 mm |
| Floor plate | HB 450 (Hardox) - 8 mm |
| Body plates | S700MC – 6 mm |
| Minimal curve radius (Single vagon) | R 35 m |
| Brake system | Classic Brake System |
| Brake Configuration | KE-GP-A(K) / Knorr- Bremse |
| Bogie Type | Y25Lsd-K H Tipi |
| Wheelset | BA 303 (25 t) veya ULT25 (25 t) |
| Wheel Diameter | 920 mm |
| Bogie Wheelbase | 1800 mm |
| Gauge | G1 |
| International usability | TEN-GE |
| Buffers type | Cat A 105 mm, 35 kJ (EN 15551) |
| Buffers type | 1500 kN (EN 15566) |
| Draw hook | 1500 kN (EN 15566) |
| Screw coupler | 1350 kN (EN 15566) |
HIGH PERFORMANCE
IN EUROPEAN STANDARDS
Designed for maximum safety and durability, our head beam bogie system delivers best-in-class performance in heavy-duty transport with 22.5 tonnes of axle pressure.
LONG LASTING DESIGN
HIGH PAYLOAD CAPACITY
UIC AND TSI CERTIFIED
STANDARD LINE WIDTH
LOW MAINTENANCE COST
